Type 6 - Directed DS4+ Installation Manual

Type 6

Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of each special note referenced in the diagram (
Autolight:
Pink, pin 8
CUT
HS CAN High:
HS CAN Low:
Yellow, pin 14
Black, pin 13
20 22 23 27 29
8 10 12 13 14 15 16 17 18
2 5
(-) Lock: Blue, pin 29
(-) Unlock: Lt. Green, pin 2
25
ENGINE
5 4
START
STOP
10 9 8 7 6
(-) PTS:
Gray, pin 5
White Conn.
(at Main Body ECU)
Steering Lock conn.
(Black conn. located at
steering lock conn.)
(-) SLP: Red,
pin 4
PTS Button
(Black conn.
3 2 1
at PTS switch)
Siren
Hood Pin
Autolight Interrupt (conn. side): Blue/White: 1
36 27 12
26
11
34 25
10
33 24
32 23
9
31 22
30 21 8
29 20
7
28 19
18 6
17 5
16 4
15 3
14 2
(+) 12V:
Blue, pin 13
13 1
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
(-) SLP Output: Lt. Green/Black: 1
(-) Lock Output: Dk. Green/Black: 3
(-) Unlock Output: Dk. Blue/Black: 9
(-) Push-to-Start Output: Lt. Blue/Black: 10
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
Autolight Interrupt (veh. side): Blue: 3
(+) 12V Input: Red: 6 & 12
(-) Ground: Black: 10
White Conn.
(at Main Body ECU)
).
DS4+ DS4
Proper Fuse
Positioning
DS4
Slide
DS4+
to open
It is important to check that the
fuses are positioned correctly.
DS4+ TL8
