Directed DS4+ Installation Manual page 17

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information
Function
Toyota Highlander (Smart Key) 2014-2016
12V
SLP
PTS
HS CAN High
HS CAN Low
Autolight
Lock
Unlock
Toyota Highlander Hybrid 2014-2016
12V
SLP
PTS
HS CAN High
HS CAN Low
Autolight
Lock
Unlock
Toyota Tacoma (Smart Key) 2016-2017
12V
SLP
PTS
HS CAN High
HS CAN Low
Autolight
Lock
Unlock
17
OEM Remote Start Location:
2014-2016 Highlander
(Smart key) & Hybrid
Color Pin Polarity
Green 1 (+)
Lt. Green 4 (-)
Yellow 5 (-)
Violet 6 Data
White 14 Data
Black 8 Cut
Violet 29 (-)
Lt. Blue 2 (-)
Green 1 (+)
Lt. Green 4 (-)
Yellow 5 (-)
Violet 6 Data
White 14 Data
Black 8 Cut
Violet 29 (-)
Lt. Blue 2 (-)
Black 1 (+)
Tan 4 (-)
Tan 5 (-)
Lt.Blue 6 Data
White 14 Data
White 8 Cut
Lt.Blue 29 (-)
Green 2 (-)
Connector Information
Location
Dash fuse box.
Steering lock connector.
Engine start/stop switch.
OBDII under driver dash.
OBDII under driver dash.
Main body ECU.
Main body ECU.
Main body ECU.
Dash fuse box.
Steering lock connector.
Engine start/stop switch.
OBDII under driver dash.
OBDII under driver dash.
Main body ECU.
Main body ECU.
Main body ECU.
Dash fuse box.
Steering lock connector.
Engine start/stop switch.
OBDII.
OBDII.
Main body ECU.
Main body ECU.
Main body ECU.
Color Pins Ref.
White 1 A
Black 7 B
Black 10 C
White 16 D
White 16 D
White 30 E
White 30 E
White 30 E
White 1 A
Black 7 B
Black 10 C
White 16 D
White 16 D
White 30 E
White 30 E
White 30 E
White 1 A
Black 7 B
Black 10 C
White 16 D
White 16 D
White 30 E
White 30 E
White 30 E
DS4+ TL8
