• VREF_DDR used to supply the DDR reference voltage
– Value: 1.65 V
• VTT_DDR (LDO3) used to supply the termination resistors of the DDR
– Value: 1.65 V
• 1V8_Audio (LDO1) used to supply the digital/analog of the audio codec
– Value: 1.8 V
• 1V2_HDMI (LDO6) used to supply the digital core and analog part of the HDMI transceiver
– Value: 1.2 V
• 3V3_HDMI (LDO2) used to supply the I/Os of the HDMI transceiver
– Value: 3.3 V
• VDD_USB (LDO4) used to supply the USB phy of the STM32MP157x
– Value: 3.3 V
7.3

Clock sources

7.3.1

LSE clock references

The LSE clock references on the STM32MP157x microprocessor are provided by the external crystal X2:
• 32.768 kHz crystal from NDK : reference NX2012SA
7.3.2

HSE clock references

The HSE clock references on the STM32MP157x microprocessor are provided by the external crystal X6:
• 24 MHz crystal from NDK : reference NX2016SA
7.4

Reset sources

The reset signal of STM32MP157A-DK1 and STM32MP157C-DK2 is active low. The internal PU forces the RST
signal to a high level.
The sources of reset are:
• Reset button B2 (black button)
• STPMIC1
• Embedded ST-LINK/V2.1
™
• Arduino
• STM32MP157x
7.5

Boot mode

7.5.1

Description

At startup, the boot source used by the internal bootROM is selected by the Boot pins.
configurations of the Boot pins.
Boot 0
0
1
0
1
1. Pin Boot 1 is always tied to "0" by a pull-down resistor.
Figure 7 shows the configurations of the boot-related switch SW1.
UM2534 - Rev 1
connector CN16: pin 3, reset from the Arduino
(1)
Boot 1
0
0
0
0
™
board
Table 5. Boot mode pins
Boot 2
0 Forced USB boot for flashing.
0 Not supported.
1 Reserved.
1 SD card on SDMMC1.
UM2534
Clock sources
Table 5 describes the
Boot mode
page 12/47
