The resolution is up to 720p60 (1280 × 720).
Input signals are 24 bits digital RGB (LTDC) for the video and I2S2 for the audio. Refer to the STM32MP157x
datasheet for details.
The control signals are I2C1, one interruption, and a dedicated reset.
The Consumer Electronic Control (CEC) is also available through the HDMI
7.12.2
®
HDMI
I/O interface
Table 15
describes the I/O configuration for the HDMI
I/O
PB6
PD9
PG12
PG10
PD10
PI4
PA3
PB8
PD8
PE5
PE6
PH13
PH14
PH15
PI0
PI1
PI2
PH2
PH3
PH8
PH9
PH10
PC0
PH12
PE15
PG7
PF10
PI10
PI9
PA9
PB9
PI3
