Table 24. Pinout Of The Arduino - ST STM32MP157C-DK2 User Manual

I/O
PD15
PE9
PD1
PG3
PH6
PE11
PE14
PE13
PE12
PA12
PA11
Table 24 describes the pinout of the Arduino
Connector
CN16
CN17
CN14
UM2534 - Rev 1
HW
- PD15 is used as ARD_D5: TIM4_CH4
- PE9 is used as ARD_D6: TIM4_CH1
- PD1 is used as ARD_D7: IO
- PG3 is used as ARD_D8: IO
- PH6 is used as ARD_D9: TIM12_CH1
- PE11 is used as ARD_D10: SPI4_NSS, TIM1_CH2
- PE14 is used as ARD_D11: SPI4_MOSI ,TIM1_CH4
- PE13 is used as ARD_D12: SPI4_MISO
- PE12 is used as ARD_D13: SPI4_SCK
- PA12 used as ARD_D14: I2C5_SDA shared with ARD_A4 (SB23 ON / SB24 OFF)
- PA11 used as ARD_D15: I2C5_SCL shared with ARD_A5 (SB25 ON / SB26 OFF)
Table 24. Pinout of the Arduino
Pin name Signal name
1
2
3
4
5
6
7
8
1
2
3
4
5
6
1 ARD_D0
2 ARD_D1
3 ARD_D2
4 ARD_D3
5 ARD_D4
6 ARD_D5
7 ARD_D6
8 ARD_D7
Configuration
™
connectors.
™
connectors
STM32 pin
NC -
3V3 -
NRST NRST
3V3 -
5V -
GND -
GND -
VIN
A0 PF14
A1 PF13
A2 ANA0
A3 ANA1
A4 PC3/PA12
A5 PF12/PA11
PE7
PE8
PE1
PD14
PE10
PD15
PE9
PD1
UM2534
Arduino™ connectors
Comment
NC (reserved for test)
IOREF 3V3
NRST
3V3
5V
GND
GND
Not connected
ADC1_IN0
ADC1_IN1
ADC1_IN6
ADC1_IN2
ADC1_IN13
USART7_RX
USART7_TX
IO
TIM4_CH3
IO
TIM4_CH4
TIM1_CH1
IO
page 29/47
