ST STM32MP157C-DK2 User Manual page 34

Ball
W2
T4
Y1
U2
Y2
V2
AA1
W1
AA2
U3
AB3
U4
AA4
V3
V4
AB1
AB2
AC3
AA6
Y6
AA3
AB6
Y4
AA7
AC4
Y5
AB4
AB7
AC7
Y9
Y10
AB8
AC8
AB5
Y3
AC5
AA10
Y8
Y7
Y11
UM2534 - Rev 1
Pin
PC3 ARDUINO_A4_ADC1_IN13
PG3 ARDUINO_D8_GPIO
PE2 ETH_TXD3
PA3 LTDC_B5
PC2 ETH_TXD2
PG2 GPIO5_MCO2
PG14 ETH_TXD1
PG1 HDMI_INT_GPIO
PG13 ETH_TXD0
ANA0 ARDUINO_A0_ADC1_IN0
PA0 PA0_WKUP_PMIC_INT
ANA1 ARDUINO_A1_ADC1_IN1
PA1 ETH_REF_CLK
PA5 TypeC_Power_CC2_ADC1_IN19
PA4 TypeC_Power_CC1_ADC1_IN18
PB11 ETH_TX_EN
PG4 ETH_GTX_CLK
PA2 ETH_MDIO
PC1 ETH_MDC
PG5 ETH_CLK125
PH3 LTDC_R1
PB0 ETH_RXD2
PF15 IDSD_BOARD_I2C1_SDA
PB1 ETH_RXD3
PF14 ARDUINO_A2_ADC2_IN6
PF13 ARDUINO_A3_ADC2_IN2
PH2 LTDC_R0
PC5 ETH_RXD1
PC4 ETH_RXD0
PF12 ARDUINO_A5_ADC1_IN6
PF11 SAI2_SD_B
PA7 ETH_RXDV
PA6 ETH_MDINT
PC0 LTDC_R5
PB10 GPIO14_USART3_TX
PB12 GPIO15_USART3_RX
PB13 GPIO16_USART3_CTS_NSS
PB5 ETH_ETH_CLK
PG11 STLK_UART4_TX
PH6 ARDUINO_D9_TIM12_CH1
STM32MP157A-DK1 and STM32MP157C-DK2 I/O assignment
Assignment
UM2534
page 34/47
