Ball
C19
A8
D11
B9
B8
C9
A7
D10
B7
C10
D8
A5
D9
B6
D7
B5
D6
C8
D5
C5
A4
B4
A3
C4
C6
D3
B3
UM2534 - Rev 1
Pin
PA15 DSI_LCD_BLCTRL_TIM2_CH1/2_ETR
PA9 HDMI_I2S2_SCK/2_CK
PB7 uSD_detect_GPIO
PD1 ARDUINO_D7_GPIO
PD0 WLAN_HOST_WAKE_GPIO
PE3 WLAN_SDMMC2_CK
PD5 BT_USART2_TX
PD7 GPIO27_SDMMC3_D3
PG15 GPIO22_SDMMC3_CK
PE6 LTDC_G1
PF0 GPIO24_SDMMC3_D0
PF1 GPIO23_SDMMC3_CMD
PF4 GPIO25_SDMMC3_D1
PD4 BT_USART2_RTS
PF5 GPIO26_SDMMC3_D2
PD10 LTDC_B3
PE0 SAI2_MCLK_A
PE1 ARDUINO_D2_GPIO
PH8 LTDC_R2
PH9 LTDC_R3
PE11 ARDUINO_D10_SPI4_NSS/TIM1_CH2
PE12 ARDUINO_D13_SPI4_SCK
PE13 ARDUINO_D12_SPI4_MISO
PH11 GPIO6_TIM5_CH2
PE14 ARDUINO_D11_SPI4_MOSI/TIM1_CH4
PE15 LTDC_R7
PH4 WLAN_REG_ON_GPIO
STM32MP157A-DK1 and STM32MP157C-DK2 I/O assignment
Assignment
UM2534
