10

Measurements

Pos: 256 /Te chnis che Dok umenta tion/A lle G eräte/ Überschr ifte n/Üb erschrif te n 1.1/ L/Übersc hrift 1.1: Last- Sim ula tion @ 13\mod_ 1234355592656_75.d ocx @ 339173 @ 2 @ 1
10.1

Load Simulation

Pos: 257 /Te chnis che Dok umenta tion/ Leis tungsmesstechnik/POWE RDYNO/052301 LPS 3000 R100/BA/Inhalt: 0523 Last- Sim ula tion @ 13\mod_ 1234355913919_75.d ocx @ 339199 @ @ 1
The Load simulation menu enables the user to preselect various load conditions which, for exam-
ple, make possible targeted engine diagnosis or determination of the climbing performance of a
vehicle. After selecting the menu item, the following screen appears:
• Const. traction
• Const. speed
• Road load simulation
Pos: 258 /Te chnis che Dok umenta tion/A lle G eräte/ Überschr ifte n/Üb erschrif te n 1.1.1/I/Üb erschrif t 1.1.1: Ide ntisc he Funktione n @ 13\m od_1234356750341_ 75.docx @ 339225 @ 3 @ 1
10.1.1

Identical Functions

Pos: 259 /Te chnis che Dok umenta tion/ Leis tungsmesstechnik/POWE RDYNO/052301 LPS 3000 R100/BA/Inhalt: 0523 Buttonbes chreib ung @ 13\m od_1234356903390_ 75.docx @ 339251 @ @ 1
Button Description
LEVEL 1
Target
value +/-
Target
value OK
Start
Stop
Driving cycle
Evaluate
LEVEL 2
Store
Reset
Profile
Reset travel
distance
LEVEL 3
Enter target
value
Pos: 260 /-----Format- ----/MANUE LLE R UMBRUCH Se ite numbruch @ 0\mod_ 1134403577687_0.docx @ 1277 @ @ 1
• Const. Engine RPM
• Standstill
F5 • The target value can be changed and confirmed during the measure-
ment.
Change the value with the +/- keys or with the remote control scroll key.
F5
If the desired value is set, it is confirmed with the <F5> key.
F6
• The graphic recording of the measurement is started or stopped.
F6
F7 • A driving cycle from the database can be selected.
F8 • The measurement evaluation is displayed.
F5 • The measurement is stored.
F6 • The graphic recording of the measurement is reset to zero.
F7 • A display profile can be selected from the database.
F8 • The travel distance measurement is reset to zero.
• Use this button to change the current target value (e.g. Speed 50 km/h)
without having to quit the program.
• Drive dyno
• Show last measurement
BA053101-en
69
