MAHA POWERDYNO MSR Series Original Operating Instructions page 30

30
Pos: 105 /Te chnis che Dok umenta tion/ Leis tungsmesstechnik/POWE RDYNO/052301 LPS 3000 R100/BA/Inhalt: 0523 S chnittstelle nbox ( Tex t 2) @ 13\m od_1234252898101_ 75.docx @ 336301 @ @ 1
DRZ
PTH
OBD (Option)
P2T2 (Option)
Pos: 106 /Te chnis che Dok umenta tion/ Leis tungsmesstechnik/POWE RDYNO/052301 LPS 3000 R100/BA/Inhalt: 0523 S chnittstelle nbox- Be le gung ( Tex t) @ 13\m od_1234253839295_ 75.docx @ 336327 @ @ 1
Display the Interface Box Assignment
1 The assignment of the interface box appears using the keys <SHIFT> + <F1> .
2 Use <CONTINUE> or <RETURN> to exit this screen.
Pos: 107 /Te chnis che Dok umenta tion/ Leis tungsmesstechnik/POWE RDYNO/052301 LPS 3000 R100/BA/Inhalt: 0523 S chnittstelle nbox- Be le gung ( Bild) @ 13\m od_1234254152771_ 0.d ocx @ 336353 @ @ 1
Pos: 108 /-----Format- ----/MANUE LLE R UMBRUCH Se ite numbruch @ 0\mod_ 1134403577687_0.docx @ 1277 @ @ 1
BA053101-en
A Piezo clamp, TDC sensor Light barrier
B Piezo clamp, TDC sensor Light barrier
C Oil temperature probe
D Trigger tongs
E Fuel temperature
F Intake air temperature
G Atmospheric pressure
H Humidity sensor
I OBD
J Pressure 1
K Pressure 2
L Temperature 1
M Temperature 2
