16.4

Sensor Module Cabinet 30 (SMC30)

Pos: 431 /Te chnis che Dok umenta tion/ Leis tungsmesstechnik/POWE RDYNO/053101 M SR/ BA/Inhalt: 0531 SINAMICS Se nsor M odule Cab inet 30 (SMC 30) @ 17\mod_ 1253261947128_ 75.docx @ 444732 @ @ 1
LED Color
-
Green
Orange
RDY
Red
READY
Green / Red
Green /
Orange
or
Red / Orange
-
OUT > 5V
Orange
Pos: 432 /-----Format- ----/MANUE LLE R UMBRUCH Se ite numbruch @ 0\mod_ 1134403577687_0.docx @ 1277 @ @ 1
BA053101-en
Status Description, Cause
Electronics power supply is missing or outside
Off
permissible tolerance range.
Steady The component is ready for operation and cy-
light clic DRIVE-CLiQ communication is taking place.
Steady DRIVE-CLiQ communication is being estab-
light lished.
At least one fault is present in this component.
Steady Note:
light
LED is driven irrespective of the corresponding
messages being reconfigured.
Flashing Firmware is being downloaded.
Component recognition via LED is activated
(p0144).
Note:
Flashing
Both options depend on the LED status when
component recognition is activated via p0144 =
1.
Electronics power supply is missing or outside
permissible tolerance range.
Off
Power supply > 5 V.
Electronics power supply for measuring system
available.
Power supply > 5 V.
Notice:
Steady
light You must ensure that the connected encoder
can be operated with a 24 V supply. If an en-
coder that is designed for a 5 V supply is oper-
ated with a 24 V supply, this can destroy the
encoder electronics.
Remedy
-
-
-
Remedy and ack-
nowledge fault
-
-
-
-
