Analog Input Module (Optional)

Pos: 120 /Te chnis che Dok umenta tion/ Leis tungsmesstechnik/POWE RDYNO/052301 LPS 3000 R100/BA/Inhalt: 0523 A na loge inga ngsm odul (Option) ( Tex t) @ 13\m od_1234258712534_ 75.docx @ 336789 @ @ 1
The analog input module is used to record 4 analog signals (Plug-in card CAN AIN4).
Measurement data from –10 V to +10 V or from –20 mA to +20 mA can be recorded.
Pos: 121 /Te chnis che Dok umenta tion/ Leis tungsmesstechnik/POWE RDYNO/052301 LPS 3000 R100/BA/Inhalt: 0523 A na loge inga ngsm odul (Option) ( Bild) @ 13\m od_1234258797503_ 0.docx @ 336815 @ @ 1
Pos: 122 /Te chnis che Dok umenta tion/A lle G eräte/ Überschr ifte n/Üb erschrif te n 1.1/A/ Überschr ift 1.1: A nalog-Aus ga ngskarte (Option) @ 13\m od_1234259302517_ 75.docx @ 336841 @ 2 @ 1
2.8

Analog Output Card (Optional)

Pos: 123 /Te chnis che Dok umenta tion/ Leis tungsmesstechnik/POWE RDYNO/052301 LPS 3000 R100/BA/Inhalt: 0523 A na loga usgangskarte (Option) @ 13\mod_ 1234259391712_ 75.docx @ 336867 @ @ 1
The analog output card (Plug-in card LON OUTA) is used for further processing of measured
values as analog signals for an external device (e.g. analog display, digital display).
There are 4 analog outputs available from –10 V to +10 V.
The plug-in card LON OUTA is connected in the communication desk.
