2.6

Remote Control

Pos: 95 / Tec hnische Dokume ntation/Le istungsmess tec hnik/PO WERDYNO/052301 LPS 3000 R100/ BA/Inhalt: 0523 Fernbed ienung ( Tex t) @ 13\m od_1234179191060_ 75.docx @ 335824 @ @ 1
The functions of the program can also be selected via the remote control. The remote control can
be operated directly from the vehicle.
The signal is transmitted by radio. The receiving antenna for the signal is located in the desk.
Should several dynos each with its own remote control be operated in one room, the remote
controls must be set to different channels.
As soon as the remote control is switched on and radio connection to the dyno exists, the green
control lamp will light up permanently on the operation desk. The green control lamp will blink
briefly each time a key is pressed.
When not in use the remote control should always be stored in the re-charging box to avoid a total
discharging of the battery. The re-charging box is equipped with a "re-charge overload protection".
The re-charging time for a fully discharged battery is about 12 to 14 hours. During the re-charging
procedure the red LED on the re-charging box will light up and "Battery recharging" appears on
the display of the remote control.
To switch on the remote control press the ON key. The remote control has an automatic switch off
(Timeout) which can be variably set. The remote control switches off when no key has been
pressed during this time.
The letters on the remote control can be selected by pressing the SHIFT key. Press again to return
to the normal operation mode. The display "SHIFT" appears in the window when the SHIFT key
has been pressed.
The remote control keyboard consists of two pads: Function key pad + Number pad.
Pos: 96 / Tec hnische Dokume ntation/Le istungsmess tec hnik/PO WERDYNO/052301 LPS 3000 R100/ BA/Inhalt: 0523 Fernbed ienung ( Tabe lle) @ 13\m od_1234943754775_ 75.docx @ 342981 @ @ 1
Remote Control
Use this key to activate the lifting bar. It can then be operated with the
1
cursor keys.
2 Switch fan on / off
3 Deletes an entire line
Selection of a menu item
4 (In combination with the function key F5 and the cursor keys target val-
ues can be increased or decreased in some menus.)
5 Confirmation of inputs
Deleting the character before the cursor position
6
Discarding of inputs
7 Switch over to letter mode
8 Connection for Pedal force sensor
In some menus special functions can be opened. The key assignments
vary in the different menus. Four boxes with diverse functions are locat-
9
ed on the lower screen edge in these menus. These options are select-
ed with the function keys F5 to F8 on the remote control. If the button
bar has further levels, these can be displayed using the cursor keys.
Use this key to activate the load simulator. It can then be operated with
10
the cursor keys.
Use this key to activate the roller set adjustment. It can then be operated
11
with the cursor keys.
27
PC Keyboard
F3 + Cursor keys
F2
Return
Backspace
F5 to F8
F4 + Cursor keys
