2.2.10

MSR 1000

Pos: 75 / Tec hnische Dokume ntation/Le istungsmess tec hnik/PO WERDYNO/053101 MS R/BA/Inha lt: 0531 MSR 1000 ( Bild) @ 23\m od_1298448477424_ 0.docx @ 979192 @ @ 1
Pos: 76 / Tec hnische Dokume ntation/Le istungsmess tec hnik/PO WERDYNO/053101 MS R/BA/Inha lt: 0531 MSR 1000 ( Tex t) @ 14\m od_1241599234153_ 75.docx @ 371747 @ @ 1
4WD with 1 Eddy Current Brake and 1 E-Machine per Axle
Roller diameter
Rolling circumference
Roller length
Track width (min....max.)
Roller wall thickness
Total weight of Roller set
Mech. inertia weight
Permissible axle load
Maximum speed
Maximum speed of a tracked, non-driven axle
Motor power
Wheel power Front axle
Wheel power Rear axle
Tractive force Front axle
Tractive force Rear axle
Fuse
Supply voltage
Pos: 77 /----- Forma t-----/MAN UELLER UM BRUCH Se itenumbruch @ 0\m od_1134403577687_ 0.docx @ 1277 @ @ 1
23
762 mm / 30"
2393 mm
700 mm
900...2300 mm
20 mm
5610 kg
2 x 700 kg
2500 kg
> 300 km/h
approx. 200 km/h
2 x 30 kW
approx. 700 kW (Peak)
approx. 700 kW (Peak)
approx. 8600 N
approx. 8600 N
63 A
3 x 400 V
