Msr 800 - MAHA POWERDYNO MSR Series Original Operating Instructions

20
Pos: 62 / Tec hnische Dokume ntation/Alle Geräte/Übersc hriften/ Überschrifte n 1.1.1/M/Überschr ift 1.1.1: MSR 800 @ 24\m od_1306494127905_ 0.docx @ 1013813 @ 3 @ 1
2.2.7

MSR 800

Pos: 63 / Tec hnische Dokume ntation/Le istungsmess tec hnik/PO WERDYNO/053101 MS R/BA/Inha lt: 0531 MSR 800 (Bild) @ 23\mod_ 1298447556531_ 0.d ocx @ 979071 @ @ 1
Pos: 64 / Tec hnische Dokume ntation/Le istungsmess tec hnik/PO WERDYNO/053101 MS R/BA/Inha lt: 0531 MSR 800 (Text) @ 14\mod_ 1241597479700_75.docx @ 371613 @ @ 1
1-Axle Roller Set
Roller diameter
Rolling circumference
Roller length
Track width (min....max.)
Roller wall thickness
Total weight of Roller set
Mech. inertia weight
Permissible axle load
Maximum speed
Wheel power
Const. tractive force
Fuse
Supply voltage
Pos: 65 /----- Forma t-----/MAN UELLER UM BRUCH Se itenumbruch @ 0\m od_1134403577687_ 0.docx @ 1277 @ @ 1
BA053101-en
762 mm / 30"
2393 mm
700 mm
900...2300 mm
20 mm
1910 kg
approx. 700 kg
2500 kg
> 300 km/h
approx. 660 kW
not available
16 A
230 V + N + PE
