8.7

Bring the Vehicle up to Operating Temperature

Pos: 225 /Te chnis che Dok umenta tion/ Leis tungsmesstechnik/POWE RDYNO/052301 LPS 3000 R100/BA/Inhalt: 0523 Fahrze ug auf Betriebstempera tur bringe n @ 13\m od_1234342622317_ 75.doc x @ 338415 @ @ 1
This can be done using the load simulation, e.g. with a constant traction (see section
Simulation"
Pos: 226 /Te chnis che Dok umenta tion/A lle G eräte/ Überschr ifte n/Üb erschrif te n 1.1/ F/Übersc hrift 1.1: Fahrze ug prüfbereit @ 13\m od_1234342668088_ 75.d ocx @ 338441 @ 2 @ 1
8.8

Vehicle Ready for Testing

Pos: 227 /Te chnis che Dok umenta tion/ Leis tungsmesstechnik/POWE RDYNO/052301 LPS 3000 R100/BA/Inhalt: 0523 Fahrze ug prüfbereit @ 13\m od_1234342707843_75.d ocx @ 338467 @ @ 1
The vehicle is ready for testing when all the preparation steps for testing have been completed.
Pos: 228 /Te chnis che Dok umenta tion/ Leis tungsmesstechnik/- Archiv -/ 00 LPS A lle/Inha lte/Warnung!/Inhalt: Warnung - Lebens gef ahr durc h rotierende Prüfstandsrollen @ 14\mod_ 1241613428231_ 75.docx @ 372059 @ @ 1
Life-threatening injuries possible by rotating dyno rollers!
• Always keep body parts and clothing far away from rotating rollers, as there is danger of these
being pulled into the rotating rollers!
• Safeguard that the operating personnel is informed when someone is underneath the dyno.
Danger for those who are under the dyno without the knowledge of the operating personnel!
• If this safety system has been bypassed, the service personnel is responsible for establishing
necessary and suitable safety measures (e.g. signs which indicate that service work is being
done).
• Make sure that all keys for bypassing safety systems are only available to specially trained ser-
vice personnel.
• Do not leave the keys in the key switch during normal test operation.
Pos: 229 /Te chnis che Dok umenta tion/ Leis tungsmesstechnik/- Archiv -/ 00 LPS A lle/Inha lte/Warnung!/Inhalt: Warnung - Gef ahr v on Gehörschäden @ 14\mod_ 1241613590981_75.d ocx @ 372085 @ @ 1
Risk of hearing damage due to high noise level!
• Use ear protection which is approved for up to 120 dB(A).
Noise levels of over 100 dB(A) are possible during vehicle testing.
Pos: 230 /Te chnis che Dok umenta tion/A lle G eräte/ Überschr ifte n/Üb erschrif te n 1.1/P/ Überschr ift 1.1: Prüfs ta nd verlass en @ 14\mod_ 1241613739500_ 75.docx @ 372111 @ 2 @ 1
8.9

Exit the Dynamometer

Pos: 231 /Te chnis che Dok umenta tion/ Leis tungsmesstechnik/POWE RDYNO/053101 M SR/ BA/Inhalt: 0531 Pr üfsta nd verlasse n @ 14\mod_ 1241613800337_75.d ocx @ 372147 @ @ 1
1 Block the rollers.
2 Remove the roller adjustment device from the rear axle in a backward direction.
3 Shift into 1st gear and put on the parking brake.
4 Loosen the tightening straps at the front axle.
5 Then loosen the tightening straps at the rear axle.
6 Remove all tightening straps.
7 Release parking brake and shift into idle.
8 Drive vehicle off dyno.
Pos: 232 /-----Format- ----/MANUE LLE R UMBRUCH Se ite numbruch @ 0\mod_ 1134403577687_0.docx @ 1277 @ @ 1
BA053101-en
).
"Load
