7

Software

Pos: 178 /Te chnis che Dok umenta tion/A lle G eräte/ Überschr ifte n/Üb erschrif te n 1.1/S/ Überschr ift 1.1: Systemanforderunge n @ 11\mod_1229519508164_ 75.docx @ 284470 @ 2 @ 1
7.1

System Requirements

Pos: 179 /Te chnis che Dok umenta tion/ Leis tungsmesstechnik/- Archiv -/ 00 LPS A lle/Inha lte/Inhalt: Sys tema nf orderungen LP S-S W @ 23\mod_ 1298378719566_75.d ocx @ 978872 @ @ 1
OS
............
CPU .......................................................... > 1.6 GHz; recommended: Intel or similar AMD products
HDD .......................................................................................................... 1 GB free memory space
Graphics card ........................................ Resolution 1024 x 768 with 24 bit color depth (True Color)
RAM ............................................................................... Win XP: 512 MB; Win Vista or Win 7: 1 GB
Drives ............................................................................................................................... DVD-ROM
Interfaces ......................................................................................................... 2 free USB interfaces
• If using Win 7, please read section
stalling the application software!
• All passwords and administrator rights must be available at the time of the installation.
• If the tester is used with multiple work stations, a TCP/IP network must be available.
• For external devices with RS232 connectors an RS 232 interface must be available.
• PC speciality stores offer a wide range of USB-to-RS232 adapters. There is, however, no
standard guarantee that every adapter will function on the RS232 interfaces. For this reason,
MAHA offers adapters with the order number (VZ 910140) which have been tested on MAHA
products.
• When replacing old computers with PC-LON cards (ISA slot), be aware that new computers no
longer have ISA slots. For new computers that means that a LON-USB card (VZ 912033) is
needed for the connection to the test lane.
Pos: 180 /Te chnis che Dok umenta tion/A lle G eräte/ Überschr ifte n/Üb erschrif te n 1.1/S/ Überschr ift 1.1: Se tup s tarten @ 18\mod_ 1256737463096_ 75.docx @ 497378 @ 2 @ 1
7.2

Starting the Setup

Pos: 181 /Te chnis che Dok umenta tion/ Leis tungsmesstechnik/POWE RDYNO/052301 LPS 3000 R100/BA/Inhalt: 0523 S etup starten @ 23\mod_ 1297763792805_75.d ocx @ 976221 @ @ 1
1 Insert the CD in the
disk drive.
⇒ Installation starts
automatically.
If not, start Auto-
run.exe or EU-
ROSYSTEM\
Setup.exe
from the CD.
2 To start the setup
click the equipment
type being used.
Pos: 182 /-----Format- ----/MANUE LLE R UMBRUCH Se ite numbruch @ 0\mod_ 1134403577687_0.docx @ 1277 @ @ 1
Win XP with SP 2; Win Vista (32 Bit) for ES v7.00.015 or later; Win 7 for ES v7.10.001 or later
Additional Settings under Windows 7
51
before in-
