All about VLT 2800
PNU # Parameter description
500 Address
501 Baudrate
502 Coasting stop
503 Quick stop
504 DC brake
505 Start
506 Reversing
507 Selection of Setup
508 Selection of preset ref.
509 Bus jog 1
510 Bus jog 2
512 Telegram profile
513 Bus time interval
514 Bus time interval function
515 Data readout: Reference %
516 Data readout: Reference [unit]
517 Data readout: Feedback [unit]
518 Data readout: Frequency
519 Data readout: Frequency x scaling
520 Data readout: Motor current
521 Data readout: Torque
522 Data readout: Power [kW]
523 Data readout: Power [HP]
524 Data readout: Motor voltage [V]
525 Data readout: DC Link voltage
526 Data readout: Motor thermal load
527 Data readout: Inverter thermal load
528 Data readout: Digital input
529 Data readout: Analog input, term. 53
531 Data readout: Analog input, term. 60
532 Data readout: Pulse reference
533 Data readout: External reference
534 Data readout: Status word
535 Data readout: Bus feedback 1
537 Data readout: Inverter temperature
538 Data readout: Alarm word
539 Data readout: Control word
540 Data readout: Warning word
541 Data readout: Extended status word
544 Data readout: Pulse count
Table 5.23 Factory Settings for Parameters 500-544
MG27E402
Design Guide
Factory setting 4-set-up
1 No
9600 Baud No
Logic or Yes
Logic or Yes
Logic or Yes
Logic or Yes
Logic or Yes
Logic or Yes
Logic or Yes
10.0 Hz Yes
10.0 Hz Yes
FC protocol Yes
1 s Yes
Off Yes
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
