Programming
515-544 Data readout
Par. Description
no.
515 Res. reference
516 Res. reference [Unit]
517 Feedback [Unit]
518 Frequency
519 Frequency x scale
520 Motor current
521 Torque
522 Power[kW]
523 Power[HP]
524 Motor voltage
525 DC-link voltage
526 Thermal load motor
527 Thermal load inverter
528 Digital input
529 Term.53, analogue input
531 Term.60, analogue input
532 Pulse reference
533 External ref.
534 Status word, Hex
535 Bus feedback 1
537 Inverter temperature
538 Alarm word
539 Control word
540 Warning word
541 Extended status word
544 Pulse count
Function:
These parameters can be read out via the serial communi-
cation port and the LCP display. See also parameters
009-012 Display readout.
Description of choice:
Parameter 515 Resulting reference %:
Gives the resulting reference as a percentage in the range
from minimum reference, Ref
Ref . See also Dealing with references.
MAX
Parameter 516 Resulting reference [unit]:
Gives the resulting reference in Hz in open loop (parameter
100). In a closed loop, the reference unit is selected in
parameter 416 Process units.
Parameter 517 Feedback [unit]:
Gives the resulting feedback value with the unit/scaling
selected in parameter 414 Minimum feedback, parameter
415 Maximum feedback and parameter 416 Process units.
See chapter 4.3.1 Handling of References for more details.
Parameter 518 Frequency [Hz]:
Gives the output frequency from the adjustable frequency
drive.
Parameter 519 Frequency x scaling [-]:
MG27E402
Design Guide
Display text
(REFERENCE %)
(REFERENCE [UNIT])
(FEEDBACK [UNIT])
(FREQUENCY)
(FREQUENCY X SCALE)
(MOTOR CURRENT)
(TORQUE)
(POWER (KW))
(POWER (HP))
(MOTOR VOLTAGE)
(DC LINK VOLTAGE)
(MOTOR THERMAL)
(INV. THERMAL)
(DIGITAL INPUT)
(ANALOG INPUT 53)
(ANALOG INPUT 60)
(PULSE REFERENCE)
(EXT. REF.%)
(STATUS WORD)
(BUS FEEDBACK1)
(INVERTER TEMP.)
(ALARM WORD)
(CONTROL WORD)
(WARN. WORD)
(STATUS WORD)
(PULSE COUNT)
to maximum reference,
MIN
Danfoss A/S © Rev. May/2014 All rights reserved.
Unit
%
Hz, RPM
Par. 416
Hz
Hz
Amp
%
kW
HP
V
V
%
%
Bin
V
mA
Hz
%
Hex
Hex
°C
Hex
Hex
Hex
Hex
Corresponds to the present output frequency f
by the factor preset in parameter 008 Display scaling of
output frequency.
Parameter 520 Motor current [A]:
Gives the motor's phase current measured as an effective
value.
Parameter 521 Torque [Nm]:
Gives the motor's present load in relation to the motor's
rated torque.
Parameter 522 Power [kW]:
Gives the present power absorbed by the motor in kW.
Parameter 523 Power [HP]:
Gives the present power absorbed by the motor in HP.
Parameter 524 Motor voltage:
Gives the voltage being supplied to the motor.
Parameter 525 DC link voltage:
Gives the intermediate circuit voltage in the adjustable
frequency drive.
Parameter 526 Thermal load, motor [%]:
Gives the calculated/estimated thermal load on the motor.
100% is the cut-out limit. See also parameter 128 Thermal
motor protection.
Parameter 527 Thermal load INV [%]:
Update
interval
4 4
multiplied
M
