Programming
Ready - mains voltage within range
(RDY NO OVER/UNDERVOL)
Alarm or warning
(ALARM OR WARNING)
Current higher than current limit, par. 221
(Current limit)
Alarm (ALARM)
Output frequency higher than f
(above frequency low)
Output frequency lower than f
(below frequency high)
Output current higher than I
(above current low)
Output current lower than I
(below current high)
Feedback higher than FB
LOW
(above feedback low)
Feedback lower than FB
HIGH
(under feedback high)
Relay 123 (RELAY 123)
Reversing (REVERSE)
Thermal warning (THERMAL WARNING)
Local operation (LOCAL MODE)
Out of frequency range par. 225/226
(out of freq range)
Out of current range
(out of current range)
Out of feedback range
(out of fdbk. range)
Mechanical brake control
(Mech. brake control)
Control word bit 11
(control word bit 11)
Sleep Mode
(sleep mode)
Function:
The relay output can be used for giving the present status
or warning. The output is activated (1-2 make) when a
given condition is fulfilled.
Description of choice:
No function. Is selected if the frequency converter is not to
react to signals.
Unit ready, there is a supply voltage on the control card of
the frequency converter, and the frequency converter is
ready for operation.
Enable, no warning, the frequency converter is ready for
operation, but no start command has been given. No
warning.
Running is active when there is a start command or the
output frequency is above 0.1 Hz. Also active during ramp-
down.
Running in reference, no warning speed according to
reference.
MG27E402
Design Guide
[7]
[8]
[9]
[10]
par. 225
LOW
[11]
par. 226
HIGH
[12]
par. 223
LOW
[13]
par. 224
HIGH
[14]
par. 227
[15]
par. 228
[16]
[17]
[18]
[19]
[20]
[22]
[23]
[24]
[25]
[26]
[27]
Danfoss A/S © Rev. May/2014 All rights reserved.
Running, no warning, a start command has been given. No
warning.
Ready - mains voltage within range, the frequency converter
is ready for use; the control card is receiving a supply
voltage; and there are no active control signals on the
inputs. The mains voltage lies within the voltage limits.
Alarm or warning, the output is activated by an alarm or
warning.
Current limit, the output current is higher than the value
programmed in parameter 221 Current limit I
Alarm, The output is activated by an alarm.
Output frequency higher than f
higher than the value set in parameter 225 Warning: Low
frequency, f .
LOW
Output frequency lower than f
HIGH
lower than the value set in parameter 226 Warning: High
frequency, f .
HIGH
Output current higher than I
LOW
higher than the value set in parameter 223 Warning: Low
current, I .
LOW
Output current lower than I
HIGH
than the value set in parameter 224 Warning: High current,
I .
HIGH
Feedback higher than FB , the feedback value is higher
LOW
than the value set in parameter 227 Warning: Low feedback,
FB .
LOW
Feedback lower than FB , the feedback value is lower
HIGH
than the value set in parameter 228 Warning: High current,
I .
HIGH
Relay 123 is only used in connection with Profidrive.
Select Reversing to activate the relay output when the
direction of motor rotation is anti-clockwise. When the
direction of motor rotation is clockwise, the value is 0 V
DC.
Thermal warning, above the temperature limit in either the
motor or the frequency converter, or from a thermistor
connected to a digital input.
Local operation, the output is active when [1] Local
operation is selected for parameter 002 Local/remote
operation.
Out of the frequency range, the output frequency is out of
the programmed frequency range in parameters 225 and
226.
Out of the current range the motor current is out of the
programmed range in parameters 223 and 224.
Out of the feedback range the feedback signal is out of the
programmed range in parameters 227 and 228.
Use Mechanical brake control to control an external
mechanical brake. See chapter 3.4.13 Control of Mechanical
Brake for more details about mechanical brake control.
Control word bit 11 is active if bit 11 is high on the Bus
Communication.
Sleep Mode is active of the frequency is lower than 0.1 Hz.
.
LIM
, the output frequency is
LOW
, the output frequency is
, the output current is
, the output current is lower
