Programming
copied to the frequency converter to which the control
panel is attached. Select [3] Download size-independent
parameter to download only the size-independent
parameters. This is used when downloading to a frequency
converter with a different rated power size than that from
which the parameter set-up originates.
NOTICE
Upload/download can only be performed in stop mode.
Download can only be performed to a adjustable
frequency drive with the same software version number,
see parameter 626 Database identification no.
008 Display scaling of output frequency
Value:
0.01 - 100.00
Function:
In this parameter, the factor is selected by which the
output frequency is to be multiplied. The value is shown in
the display, provided parameters 009-012 Display readout
have been set to [5] Output frequency x scaling.
Description of choice:
Set the required scaling factor.
009 Large display readout
Value:
No readout (none)
Resulting reference [%]
(reference [%])
Resulting reference [unit]
(reference [unit])
Feedback [unit] (feedback [unit])
Frequency [Hz] (Frequency [Hz])
Output frequency x scaling
(frequency x scale)
Motor current [A] (Motor current [A])
Torque [%] (Torque [%])
Power [kW] (Power [kW])
Power [HP] (Power [HP][US])
Motor voltage [V]
(Motor voltage [V])
DC link voltage [V]
(DC link voltage [V])
Thermal load motor [%]
(Motor thermal [%])
Thermal load [%]
(FC. thermal[%])
Running hours [Hours]
(RUNNING HOURS])
Digital input [Bin]
(Digital input[bin])
Analog input 53 [V]
(analog input 53 [V])
MG27E402
Design Guide
Analog input 60 [mA]
(analog input 60 [mA])
Pulse reference [Hz]
(Pulse ref. [Hz])
External reference [%]
(external ref. [%])
Status word [Hex] (Status word [hex])
Heatsink temperature [°C]
(Heatsink temp [°C])
Alarm word [Hex] (Alarm word [hex])
Control word [Hex] (Control word [Hex])
Warning word [Hex]
(warning word [Hex])
Extended status word [Hex]
(Ext. status [hex])
1.00
Communication option card warning
(COMM OPT WARN [HEX])
Pulse count
(PULSE COUNTER)
Power [W]
(POWER [W])
Function:
Use this parameter to select the data value to display in
the LCP 2 control unit display line 2 when the frequency
converter is switched on. The display is also included in
the scrollbar in display mode. Use parameters 010-012
[0]
Display readout to select 3 more data values, which are
displayed in display line 1.
[1]
Description of choice:
No readout can only be selected in parameters 010-012
[2]
Small display readout.
[3]
Resulting reference [%] gives, as a percentage, the resulting
[4]
reference in the range from Minimum reference, Ref
Maximum reference, Ref
[5]
Reference [unit] gives the resulting reference with unit Hz
[6]
in Open loop. In Closed loop, the reference unit is selected
[7] in parameter 416 Process units.
Feedback [unit] gives the resulting signal value using the
[8]
unit/scaling selected in parameter 414 Minimum feedback,
[9]
FB , 415 Maximum feedback, FB
LOW
Frequency [Hz] gives the output frequency of the frequency
[11]
converter.
Output frequency x scaling [-] equals the present output
[12]
frequency f
Display scaling of output frequency.
[13]
Motor current [A] gives the phase current of the motor
measured as an effective value.
[14]
Torque [%] denotes the motor's present load in relation to
the motor's rated torque.
Power [kW] gives the present power that the motor is
[15]
absorbing in kW.
Power [HP] gives the present power that the motor is
[16]
absorbing in HP.
Motor voltage [V] gives the voltage supplied to the motor.
[17]
Danfoss A/S © Rev. May/2014 All rights reserved.
.
MAX
and 416 Process units.
HIGH
multiplied by the factor set in parameter 008
M
[19]
[20]
[21]
[22]
4 4
[25]
[26]
[27]
[28]
[29]
[30]
[31]
[32]
to
