1.5 Technical Data

(The technical data are valid at 23 ± 5°C and 45 ±15% rel. humidity)

1.5.1 Technical data ITC502

General Data
Line voltage
Line frequency
Max. power consumption
Supply mains overvoltage
Operating temperature
Storage temperature
Relative Humidity
Pollution Degree (indoor use only)
Warm up time for rated accuracy
Operation altitude
Weight
Dimensions (W x H x D)
Current control
Range of laser current I
Compliance voltage
Setting resolution (manual / remote control)
Measurement resolution (manual / remote control)
Accuracy
Noise without ripple (10 Hz ... 10 MHz, rms), typ.
Ripple (50/60 Hz, rms), typ.
Transients, typ.
Drift, 24 hours, typ. (0...10Hz, without changing the ambient temperature)
Temperature coefficient
Power control
Range of monitor current I
Setting resolution (manual / remote control)
1)
non condensing
2)
other ranges on request
100 V / 115 V / 230 V (-10%, +15 %) (fixed)
1)
Max. 80% up to 31°C, decreasing to 50% at 40 °C
including operating elements 220 x 120 x 376 mm
without operating elements 220 x 110 x 351 mm
LD
PD
1.5 Technical Data
50 ... 60 Hz
90 VA
Category II (Cat II)
0 ... +40°C
-40°C ... +70°C
2
≤ 10 min
< 3000 m
< 7 kg
3
3
0 ... ± 200 mA
> 6 V
10 µA / 3 µA
10 µA / 1 µA
± 100 µA
< 1.5 µA
< 1.5 µA
< 0.2 mA
< 10 µA
≤ 50 ppm/°C
2)
5 µA ... 2 mA
0.1 µA / 0.03 µA
