3.1 IEEE488 Interface

3.1 IEEE488 Interface
The IEEE488 interface of the ITC5xx-IEEE is based on the IEEE488.2 standard. This
includes the IEEE488.1 standard for the hardware settings. There is a standard 24-
pin IEEE488 jack at the rear of the unit. The address of the ITC5xx must differ from
that of other devices on the IEEE488 bus.
(Please refer to chapter 3.1.2, "Setting up the Interface", starting on page 57)

3.1.1 Interface specifications

ITC500 / page 56
Function
Source Handshake
Acceptor Handshake
Talker
Listener
Service Request
Remote/Local
Parallel Poll
Device Clear
Device Trigger
Electrical Interface
Part set
SH1
AH1
T6
L4
SR1
RL1
PP0
DC1
DT0
E1
