7.1 Technical Data

Constant Current Mode (CW)
Max. LED Current
Max. LED Forward Voltage
LED Current Limit Accuracy
Noise and Ripple
(1 Hz to 10 MHz, RMS)
TTL Modulation Mode
Input Impedance
Modulation Frequency Range
Duty Cycle Range
Modulation Waveform
TTL Lo Voltage Level
TTL Hi Voltage Level
General
Power Supply
Power Consumption
Operating Temperature Range
Storage Temperature Range
Dimensions (W x H x D)
Weight
1
) Specifications for TTL Modulation Mode depend on the forward voltage and the capacitance of the connected
SOLIS LED.
2
) non-condensing
All technical data are valid at 23 ± 5°C and 45 ± 15% rel. humidity (non condensing)
8
1
)
2
)
1 to 10 A
5.0 to 14.0 V
± (1 % + 25 mA)
typ. < 400 µA
W
10 k
DC to 1 kHz
0.2 % to 99.8 % (10 Hz)
2.0 % to 98.0 % (100 Hz)
20 % to 80% (1 kHz)
Square Wave / PWM
0.0 V to 0.8 V
2.0 V to 5.0 V
15 V DC
max. 65 VA
0 - 40 °C
-40 to 70 °C
85.4 mm x 59.6 mm x 100.0 mm
(3.36" x 2.35" x 3.94")
215 g (without power supply)
490 g (with power supply)
