THORLABS ITC502 Operation Manual page 21

Thermistor (2 kΩ / 20 kΩ range)
Measurement current
Control range
Setting resolution (manual control)
Setting resolution (remote control)
Measurement resolution (manual control)
Measurement resolution (remote control)
Accuracy
Temperature stability (24 hours)
Temperature control input
Input resistance
Control voltage
Transmission coefficient IC-sensors
Transmission coefficient thermistor (20 kΩ / 200 kΩ range)
Temperature control Output
Load resistance
Output voltage
Transmission coefficient thermistor
Transmission coefficient IC sensors
Temperature window protection
Setting range T
WIN
Setting range R
WIN
Computer Interface
Setting resolution
Measurement resolution
1)
Due to the nonlinear conversion from Ω to °C the stability in °C depends on the operating conditions
and the characteristics of the thermistor. E.g. for a typical thermistor at a set point of 10kΩ (25°C), a
0.5Ω stability translates into about 1mK temperature stability. At a set point of 5kΩ (38°C), the stability
is about 2mK.
2)
in High Resolution mode, at reduced measurement speed
1)
(20 kΩ / 200 kΩ range)
10 Ω ... 19.99 kΩ / 100 Ω ... 199.9 kΩ
0.2 kΩ/V / 2 kΩ/V ±5%
500 mV/ kΩ / 50 mV/kΩ ± 5%
50 Ω ... 2 kΩ / 500 Ω ... 20 kΩ
1.5 Technical Data
100µA / 10 µA
1 Ω / 10 Ω
0.3 Ω / 3 Ω
1 Ω / 10 Ω
0.1 Ω / 1 Ω
± 5 Ω / ± 50 Ω
≤ 0.5 Ω / ≤ 5 Ω
10 kΩ
-10 ... +10 V
2 °C/V ±5%
> 10 kΩ
0 ... ± 10 V
50 mV / °C ± 5%
0.5 °C ... 20 °C
16 Bit
2)
12 ... 18 Bit
ITC500 / page 13
