3.1.2 Setting up the Interface
Address
The device address of the ITC5xx can be changed by using the IEEE488 DIP switch
at the rear panel of the ITC5xx. SW1 to SW5 have to be set according to this table:
Address
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Continued next page
SW5
SW4
Off
Off
Off
Off
Off
Off
Off
Off
Off
Off
Off
Off
Off
Off
Off
Off
Off
On
Off
On
Off
On
Off
On
Off
On
Off
On
Off
On
Off
On
SW3
SW2
Off
Off
Off
Off
Off
On
Off
On
On
Off
On
Off
On
On
On
On
Off
Off
Off
Off
Off
On
Off
On
On
Off
On
Off
On
On
On
On
3.1 IEEE488 Interface
SW1
Off
On
Off
On
Off
On
Off
On
Off
On
Off
On
Off
On
Off
On
ITC500 / page 57
