1.5 Technical Data
Temperature control Output
Load resistance
Output voltage
Transmission coefficient IC sensors
Transmission coeff. thermistor (20 kΩ / 200 kΩ range) 500 mV/ kΩ / 50 mV/kΩ ± 5%
Temperature window protection
Setting range T
WIN
Setting range R
WIN
Computer Interface
Setting resolution
Measurement resolution

1.5.2 Technical data ITC510

General Data
Line voltage
Line frequency
Max. power consumption
Supply mains overvoltage
Operating temperature
Storage temperature
Relative Humidity
Operation altitude
Pollution Degree (indoor use only)
Warm up time for rated accuracy
Weight
Dimensions
1)
in High Resolution mode, at reduced measurement speed
2)
non condensing
ITC500 / page 10
(20 kΩ / 200 kΩ range)
2
Max. 80% up to 31°C, decreasing to 50% at 40 °C
50 Ω ... 2 kΩ / 500 Ω ... 20 kΩ
100 V / 115 V / 230 V (-10%, +15 %) (fixed)
Overvoltage category II (Cat II)
> 10 kΩ
0 ... ± 10 V
50 mV / °C ± 5%
0.5 °C ... 20 °C
16 Bit
12 ... 18 Bit
50 ... 60 Hz
150 VA
0 ... +40°C
-40°C ... +70°C
< 3000 m
≤ 10 min
< 7 kg
220 x 120 x 377 mm
1)
2
3
