8. Program example
8.1

Task of the program

The sample program is to run with the following parameters:
Parameter
Filter system
Program number
Number of phases
Irradiance (E)
Temperature control
Mode
Test chamber
temperature (CHT)
Rain
Relative humidity in %
Phase time
Switch off criterion
Total time
8.2 Solving the program task
DISPLAY TEXT
ATLAS
XENOTEST GmbH
unit __
VERSION x.y ---> ENTER
A) Input of filter system:
BASIC PARAMETERS
PROGRAM START
PROGRAMMING
MAINTENANCE
FILTER SYSTEM
EXCHANGE OF LAMP = 2
CALIBRATION
Comment: Use the „DATA" key to retrieve the possible filter systems and confirm with „ENTER".
ALPHA and HIGH
Safety instructions
ENERGY features
Function Program example
Operating manual XENOTEST ALPHA / ALPHA HIGH ENERGY
Phase 1
XENOCHROME 300
1
2
80 W/m²
Test chamber temperature
Non-turning mode
65 °C
No
40 Percent
102 min
Total time
24 hours
= 1
= 2
= 3
= 4
= 1
= 3
---> DATA
Unit set-up
Setting up tests
Phase 2
80 W/m²
Test chamber temperature
Non-turning mode
55 °C
Yes
Rain
18 min
INPUT/KEY PAD
ENTER
1
1
DATA
