6. Start-up
6.1

Filter variations

Filter / Model
XENOCHROME filters
XENOCHROME 270 (10 pcs.)
(identification I or 27)
XENOCHROME 300 (10 pcs.)
(identification II or 30)
XENOCHROME 320 (10 pcs.)
(identification III or 32)
Absorption filters
7 IR filter
(Green cutaway view)
10 window glas filter
(Light green cutaway view)
6 IR filter
(Green cutaway view)
1 Black filter
(Black filter)
4 IR filter
(Green cutaway view)
3 window glass filter
(Light green cutaway view)
6.1.1 Fitting the filters to the lantern
Wear cotton gloves to insert the filters in
order to avoid finger marks on the glass.
ALPHA and HIGH
Safety instructions
ENERGY features
Function Program example
Operating manual XENOTEST ALPHA / ALPHA HIGH ENERGY
XENOTEST ALPHA
Outer cylinder with goldrings
Filter lantern with 5 absorbers
Straight lamp
UV special glass cylinder (Suprax)
UV special glass cylinder (Suprax)
Outer cylinder with goldrings
Filter lantern without absorbers
Straight lamp
UV special glass cylinder (Suprax)
UV special glass cylinder (Suprax)
UV special glass cylinder (Suprax)
UV special glass cylinder (Suprax)
XENOCHROME filters:
Insert the 10 filters from the top into the lantern.
Turn into position.
Absorption filters:
Insert 7 filters from the top into the lantern.
Unit set-up Unit description
Setting up tests Care and cleaning
XENOTEST ALPHA HIGH ENERGY
Outer cylinder with goldrings
Filter lantern with 1 absorber
Omega-shaped lamp
Quartz outer cylinder
Outer cylinder without goldrings
Filter lantern with absorbers
Omega-shaped lamp
