4.6 Ventilation circuits ALPHA (fig.10)
1) Lamp cooling:
Fan (1) produces the exhaust air flow (2), which
cools down the xenon lamp.
2) Test chamber (fresh air operation):
The ventilation circuit of the test chamber recei-
ves fresh air (3) through a filter mat (4) at the left
side of the unit. The quantity of fresh air is control-
led by an air inlet flap (5) and warmed up by a
heating system (6). The climatic fan (7) trans-
mits the air humidified by the humidifier via air in-
take tubes (8) to the test chamber (9).
In the ALPHA, air flows from the air duct at the
rear of the unit to the samples (10). A sensor (12)
measures the temperature and relative humidity
of the test chamber exhaust air (11) under per-
manent target/value comparison. Via an exhaust
air hose (13) the air is evacuated to the outside.
4.7 Ventilation circuits HIGH ENERGY (fig.11)
Contrasts to ALPHA:
In the HIGH ENERGY unit air is directed via an air
duct (1) from the top along the samples (2).
ALPHA and HIGH
Safety instructions
ENERGY features
Function Program example
Page 24
3) Test chamber (air circulation):
During the air circulation mode the air flap (5) is
closed within the adjusting range (14) and the
air flow (15) is directed as described.
