Operating manual XENOTEST ALPHA / ALPHA HIGH ENERGY
7.1.4

Test chamber temperature

Measuring:
In the air flow of the test chamber by means of the
sensor for the test chamber temperature and rel.
humidity. Indication in the display.
Range of adjustment:
Ambient temperature up to 70°C
7.1.5 Test chamber humidity (fig. 37)
Measuring:
In the air flow of the test chamber by means of the
sensor for the test chamber temperature and rel.
humidity, indicated as percent rel. humidity in the
display.
Figure 37: Humidity diagram
100
90
80
70
60
50
40
30
20
10
0
25 30
7.2

Rain

The rain sprinkling of the entire sample surface is provided by the rain bar placed in the test chamber.
ALPHA and HIGH
Safety instructions
ENERGY features
Function Program example
Page 46
35 40 45
Test chamber temperature [°C]
Unit set-up
Setting up tests
Control:
By adding air of the laboratory in connection with
the heating system.
Range of adjustment:
In dependence on test chamber temperature and
fan speed.
Generation:
By an aerosol free ultra sonic humidifier.
Fan speed= 2000 U/min
Lamp performance = 81%
Power = 2000W
50 55 60
