Atlas XENOTEST ALPHA Operating Manual page 23

ATLAS
Figure 9: Left hand apparatus side
19
4
11
5
7
6
8
18
Before opening the lateral two-leaf doors disconnect unit from the mains.
Unplug the connection socket and secure against replugging!
1 Test chamber
2 Climatic fan
3 Filter mat
4 Heating
5 Flexible, heat resistant supply hose
to humidifier
6 Humidifier
7 Humidification hoses (4x)
8 Valve
9 Slip ring collector
10 Flap motor ventilation flap
ALPHA and HIGH
Safety instructions
ENERGY features
Function Program example
Operating manual XENOTEST ALPHA / ALPHA HIGH ENERGY
11 Ignition unit
12 Caroussel motor
13 Lifting magnet
14 Sensor for carussel speed
15 Rain pump
16 Water tank
17 Water outlet
18 Water inlet
19 Flexible, heat resistant air outlet hose
20 Fan lamp cooling
Unit set-up Unit description
Setting up tests Care and cleaning
2
1
3
9
13
14
10
12
20
15
16
17
Options und accessory Start-up
List of options and
Maintenance
accessories
Page 23
