Operating manual XENOTEST ALPHA / ALPHA HIGH ENERGY
The printer parameters (fig. 13) are
preset in the factory and must not be
changed.
Figure 14: Printer parameters
PRINT INTERVAL
PRINTER ADDRESS
DATA FORMAT
BAUDRATE
INTERFACE
CHARACTER SET
CHARACTERS/LINE
PRINT FORMAT
PRINT STRENGTH
MODE
Change of printer parameters:
1. For access to the menu, press „ M E N U /
SELECT" key for more than 3 seconds.The
following message will be printed out.
ACTUAL PARAMETER?
PRESS „ENTER"
2. Press „LINE FEED/ENTER" key. The printer
prints out current parameters and shows the
following message.
CHANGE OF PARAMETERS?
ALPHA and HIGH
Safety instructions
ENERGY features
Function Program example
Page 28
NO
00-PRINT ALWAYS
8 NO PARITY
9600
SERIAL
NATIONAL LANGUAGE
40
NORMAL
ON LINE
3. To change the printer parameters, press
„LINE FEED/ENTER" and „MENU/SELECT"
for more than 4 seconds. Afterwards the sin-
gle parameters are listed and can be con-
firmed by pressing „LINE FEED/ENTER"
or be changed by pressing „MENU/
SELECT".
4. To exit the menu programm, press „MENU/
SELECT" and „LINE FEED/ENTER" keys
simultaneously, or the program is
automatically terminated after 3 minutes
without actuating any key.
