4.1.1 Program control (fig. 4)
The control panel on the front side of the apparatus
controls and regulates the course of the entered
weathering program. The program keyboard can
Figure 4: Program control
8
7
6
1 4-line LCD display for user guidance and
data display
2 Data key for data display
3 Print key to print out the stored program,
parameter measurements and system
status from the printer
4 Program input keyboard
5 Enter key to confirm the input values
6 Escape key
7 Key-operated switch to allow locking
of the keyboard when the system is
running
8 START key
ALPHA and HIGH
Safety instructions
ENERGY features
Function Program example
Operating manual XENOTEST ALPHA / ALPHA HIGH ENERGY
11
10
9
0
1
Start Sto p
Unit set-up
Setting up tests
be locked during operation of the machine against
unauthorized access by means of a key-operated
switch.
1
12
1 2 3
DAT A P RIN T
4 5 6
7 8 9
0
ES CAP E E NTER
9 Green LED light comes on when main
switch is on
10 STOP key
11 Red LED flashes when the program is
interrupted with the STOP key or when
the system is defective. The red LED is
continuously on when certain limit values
are exceeded
12 Key to interrupt the rotation of the
specimen holder carousel during a running
program resp. to move the carousel when
a program is interrupted (When door is
closed)
