Figure 34: Insertion of the XENOSENSIV sensor
1 Fixing screws (2x)
2 XENOSENSIV sensor
3 Adapter
ALPHA and HIGH
Safety instructions
ENERGY features
Function Program example
Operating manual XENOTEST ALPHA / ALPHA HIGH ENERGY
2
3
1
Unit set-up
Setting up tests
5
6
4
4 Connection cable
5 Measuring of irradiance
6 Measuring of black standard temperature
