3. Unit set-up
3.1

Scope of delivery

Supply in a suitable case. Scope of delivery of LM-
W versions:
1. Control system with display and operating
keyboard,
2. 1 Xenon lamp,
3. non-turning-, and turning mode gearing with
connection for XENOSENSIV sensor,
4. sensor to measure test chamber
temperature and rel. humidity,
5. XENOSENSIV sensor to measure the
irradiance and the black standard tem-
perature,
6. end plug for operation without
XENOSENSIV sensor,
7. adapter to fit XENOSENSIV in test cham-
ber,
8. outer cylinder made of special UV glass
(Suprax),
9. water tank,
10. Thermo printer,
11. interface RS232 / RS485
12. Technical documentation:
- Operating manual
- Software documentation
- Circuit diagrams
- Spare part lists
Sensitive components such as:
1. Xenon lamp,
2. XENOSENSIV sensor,
3. Outer cylinder,
are packed separately.
Additional sample holders and optical
filter sysytem are necessary for the run-
ning of the unit.
ALPHA and HIGH
Safety instructions
ENERGY features
Function Program example
Page 12
3.2 Space requirements
3.2.1
• Set up the unit in a air-conditioned and air-
filtered laboratory at 18°C - 25°C and a rela-
tive air humidity of max. 50%.
• Supply an amount of approx. 300m
hour via an air filter to the laboratory (filter
type EU 4).
• Keep the laboratory free of dust.
3.2.2
• The exhaust hoses for the lamp and the test
chamber must be made of flexible
heatresistant material, as the temperatures
of the exhaust air may reach up to a max. of
120°C.
• The max. length of the exhaust hose is
limited to 3m including the option of two 90
degree bends.
• In case of longer exhaust air ducts or with
more than two 90 degree bends an external
blower is needed.
3.2.3
The electrical connection to the mains has
to be made by an electrical specialist. The
unit is designed for a mains supply of
230V +/- 10%. Different voltages are
obtainable by fitting mains trans-formers.
Connection is ensured by (1,N,PE or 2,
PE), CEE (32A, 3pol.,6h).
• For the electrical supply observe UVV
VGB 4.
• Mains conditions have to agree with the
data on the name plate.
• Observe VDE- and technical connection
regulations of the energy supply compa-
nies.
