Operating manual XENOTEST ALPHA / ALPHA HIGH ENERGY
5.2 Accessory
Helpful accessories for the operation with ALPHA and HIGH ENERGY.
For reference numbers please refer to the table on page 61.
5.2.1

Filter system

The ALPHA and HIGH ENERGY are used to si-
mulate the solar or global spectrum with filtered
xenon lamp radiation. To realise the various stan-
1. XENOCHROME filter system (fig. 17)
Consists of a filter lantern (2) with 5 absorbers
(ALPHA) or 1 absorber (HIGH ENERGY) (3), and
10 filters (4) with corresponding outer cylinder
(5).
Different spectral energy distribution va-
lues can be obtained by varying the op-
tical filters and the outer cylinder (see
fig. 18, 19, 20 and 21).
A) XENOCHROME 270 (I, 27)
with quartz cylinder,
B) XENOCHROME 300 (II, 30)
with UV special glass cylinder (Suprax),
C) XENOCHROME 320 (III)
with UV special glass cylinder (Suprax),
ALPHA and HIGH
Safety instructions
ENERGY features
Function Program example
Page 30
dards and test specifications a XENOCHROME-
and absorption filter systems are at your dispo-
sal.
Identification of XENOCHROME filters:
identification with the numbers I,II,III or 27, 30
und 32 at the bottom end of the filter.
Unit set-up Unit description
Setting up tests Care and cleaning
Options und accessory Start-up
List of options and
Maintenance

accessories
