6. Trim the red lead to the proper length. Strip the end of the red lead as required. Crimp
the large lug on the red lead.
7. Locate the fuse holder as close to the battery as possible and away from hot engine
parts. Cut the red lead at this location and pull both cut ends through the fuse holder
holes. Strip both ends and crimp the metal fuse holder ends on both ends. Install the
fuse and close the fuse holder.
8. Connect the red lead lug to the battery positive (+) terminal.

RF Cables

The following RF cables are provided with the respective In-Band DVR Models:
Order
PN
Code
7W083X17-01 DDN9034
7W083X16-01 DDN9033
7W900X94-02 DDN2719A

Table 6 DVRS RF Cables

Control Cables

The following Control Cable types are available:
Part Number:
Order Code
Description
Connector Type - Mobile
Radio End
Connector Type - DVR
Length

Table 7 DVRS Control Cable Types

January 2019
DVRS Installation & Programming Guide – PART I
Description
MSU to in-band
filtering
DVR Ant to In-Band
Filtering
APX8500 to Notch
filter
7W083X05-01
DDN9028
Standard MSU – DVR Control
Cable
DB25 Male
Over-molded 20-PIN Female
End
915mm (36")
(Custom lengths up to
7620mm = 300" are
available)
APX Series P25 Interface
Length Connectors DVR Models
Mini UHF
3 feet
male
Mini UHF
3 feet
male
QMA/Mini
3 feet
UHF
1W083B09-01
DDN9029
Optional MSU – DVR Control
Cable.
Used when the MSU is
interfaced to Siren
HLN1439C
DB25 Male → to MSU
DB25 Female → to Siren
Cable
Over-molded 20-PIN Female
915mm (36")
8M083X25 R14
All In-Band
Models.
VHF & UHF
In-Band
Models.
All In-Band
Models.
