Field Name
ANI 5 Tone Type EEA
CCIR
EIA
Emergency
Cancel
Analog Signaling Disable
Type ANI 5-Tones
DTMF
Emergency OFF-1200sec
Cancel
Timeout
Emergency number
Cancel
ANI Code
FG Emergency Local
Destination System
Both
Disable DVR Yes / No
Emergency Call
State
Use MSU Yes/No
Emergency ID
Digital
Emergency Enable /
DVR Emergency Disable check
Echo ACK box
Enabled
January 2019
DVRS Installation & Programming Guide – PART II
Range Description
Determines the ANI 5-Tone
Type.
Must match the Analog PSU
programming.
If enabled, the DVR will clear
the emergency upon detection
of the programmed Emergency
Cancel Code.
If programmed, the DVR will
automatically clear the
emergency upon expiration of
the programmed timer.
This field specifies the
Emergency Cancel ANI /DTMF
Code sequence. Must match
the Analog PSU programming.
Determines the routing of
Emergency message received
by the DVR from a Local PSU
on a FG enabled DVR channel.
When enabled, if emergency
alarm or call was declared by
an analog PSU, the DVR enters
Emergency Call State and
remains in this state until all the
MDC PSU emergencies are
cancelled by the PSU or DVR.
While in Emergency Call State
DVRS would forward all calls
received from the analog PSUs
without leading PTT ID as
emergency calls. Calls received
from analog PSUs with the
leading PTT ID would be
handled accordingly. The DVR
Emergency Call State is
cancelled by pressing the
DVRS button, by
preprogrammed emergency
cancel timer or remotely via
Emergency Cancel ANI code.
When enabled the MSU ID is
used instead of the PSU ID to
proxy Emergency alerts.
Must be Disabled when using
Generic P25 PSUs since they
will treat signaling level Ack as
application level Ack. Must be
Enabled when using DVRS
Enabled PSUs and 'Console
Ack'.
8M083X25 R14
APX Series P25 Interface
Notes
Affects Analog Mode only.
Affects Analog Mode only.
Affects all modes.
Affects Analog Mode only.
Applicable only if the Emergency
Cancel Signaling Type Field is
Enabled.
The PSU must be programmed
with * as the last DTMF sign, for
example 456*.
Applicable to DVR channels which
have FG signaling enabled.
Applicable to Analog DVR mode
and analog PSUs only.
Applicable to Analog DVR mode
and analog PSUs only.
Requires 'Digital Emergency
Portable Ack Required' to be
Enabled.
