Personality Data Setup

Repeater Channel Setup Menu

Field Name Options
/ Units
Ch # 1-192
Name Seven (7)
character
string
Channel Mode F. Duplex
Simplex
Fire Ground Yes / No
Channel Type Digital
Analog
Mixed
F.Analog
TPS
FA-All
Rx Freq [MHz]
Rx PL [Hz] / DPL
Tx Freq [MHz]
Tx PL [Hz] / DPL
PL STE [deg] /
DPL
VR Mode System
Local
User
Manual Mode Enabled
Change Disabled
Tx Pwr 30-40
dBm
January 2019
DVRS Installation & Programming Guide – PART II
Description
DVR Channel Number – referenced
in the Mobile Radio Channel Setup
when associating DVR channels to
Mobile Radio Modes.
DVR Channel name (alias)
displayed on the Control Head
when the DVR is enabled.
Determines the DVR mode of
operation for the specific channel –
Full Duplex or Simplex.
Enables or Disables Fireground
Signalling Capabilities on the
selected DVR channel.
Defines the DVR Channel Type.
Mixed Mode is selected when the
same DVR channel will be used by
Analog and P25 PSUs.
DVR Rx Frequency (Must match
the PSU Tx Frequency).
DVR Rx PL / DPL (Must match the
Analog PSU Tx PL/DPL).
DVR Tx Frequency (Must match the
PSU Rx Frequency).
DVR Tx PL / DPL (Must match the
Analog PSU Rx PL/DPL).
Analog PSU PL/DPL Squelch Tail
Elimination – must be programmed
to match the PSU.
Determines the Default DVR mode
when this DVR channel is selected.
TG Mode (Mobile Radio Channel
Setup) overwrites this setting.
Enables / Disables the DVR mode
change from the VRS button on the
Control Head. If this field is set to
Disabled, the VRS button still
toggles between the default DVR
mode and OFF mode.
Specifies the selected Tx Output
Power at the DVR Antenna Port on
the DVR Tx frequency.
8M083X25 R14
APX Series P25 Interface
Notes
Read Only Field.
Fireground (FG) signaling can be
enabled on analog or digital DVR
channels only.
Applies to Analog, Mixed and F.
Analog Mode Only.
Applies to Analog, Mixed and F.
Analog Mode Only.
Applies to Analog, Mixed and F.
Analog Mode Only.
This field is automatically set to
Enabled when the VR Mode is set
to User.
The Duplexer Tx Insertion Losses
as entered in the Interface to
Mobile Setup screen are
compensated by the DVR PA
Output to produce the
programmed Tx Power at the
Antenna Port.
