DVR Programming

The following paragraphs provide detailed DVR programming information.
IMPORTANT!
Do not change DVR settings unless fully familiar with the meaning of a specific
option. The Tweaker program reports any obvious errors and does not allow invalid
data to be saved to the DVR, however, not all inconsistencies can be reported by
the Tweaker. Successful DVRS programming requires thorough understanding of
the DVR, MSU and PSU programming as well as the specific User / System
requirements. Only when all templates (DVR, MSU and PSU) are matched, the DVRS
will operate properly. For instance, changing the APX MSU template may require
corresponding update of the DVR template, which in turn may require update of the
PSU template.

Repeater Setup

RF/Analog Setup

The values in this menu are set to the correct settings upon shipping from the Futurecom
factory. No changes to those values are required unless instructed otherwise by
Futurecom.

Frequency Band Setup

This screen is used for selecting the adjacent channel separation. Two selections are
possible – Set 1 and Set 2, which can be either Narrowband (12.5kHz) or Wideband
(25kHz). Ensure the correct spacing (Set 1 or Set 2) is selected to match the portable
radio programming on each DVR channel – see "Repeater Channel Setup" screen,
'Bandwidth' field.

User Text

This screen is provided for template maintenance purposes. The DVR personality
templates can be dated and referenced from this Menu screen by entering an applicable
template / project description and revision.

DVR Info

This screen is for information only and it displays the firmware revisions, model and serial
number of the DVR.
