Table 2 Vhf Dvrs Configurations - Futurecom P25 Installation & Programming Manual

Here is a simple table of possible MSU /DVR channel band configurations:
MSU DVR
Single
Band In-Band
Single Cross-
Band Band
Multiband In-Band
Cross-
Multiband Band
APX MSU Model
Dual Band APX MSU
700/800MHz & VHF
Dual Band APX MSU
700/800MHz & UHF R1
Dual Band APX MSU
700/800MHz & UHF R2
Dual Band APX MSU
UHF R1 & VHF
Dual Band APX MSU
UHF R2 & VHF
Dual Band APX MSU
UHF R1 & UHF R2
Single Band APX MSU
VHF
Single Band APX MSU
UHF R1
Single Band APX MSU
UHF R2
Single Band APX MSU
700 / 800MHz

Table 2 VHF DVRS Configurations

January 2019
DVRS Installation & Programming Guide – PART I
MSU In-Band Filter
IN
OUT
IN
OUT
VHF (136-174MHz)
DVRS Models
•
X-Band with band locked VHF, Full Duplex
•
X-Band with band locked VHF, Simplex
•
In-Band & X-Band Capable, Full Duplex
•
In-Band & X-Band Capable, Simplex
•
X-Band Full Duplex
•
X-Band Simplex
•
X-Band Full Duplex
•
X-Band Simplex
•
X-Band with band locked VHF, Full Duplex
•
X-Band with band locked VHF, Simplex
•
In-Band & X-Band Capable, Full Duplex
•
In-Band & X-Band Capable, Simplex
•
X-Band with band locked VHF, Full Duplex
•
X-Band with band locked VHF, Simplex
•
In-Band & X-Band Capable, Full Duplex
•
In-Band & X-Band Capable, Simplex
•
X-Band Full Duplex
•
X-Band Simplex
•
In-Band Full Duplex
•
In-Band Simplex
•
X-Band Full Duplex
•
X-Band Simplex
•
X-Band Full Duplex
•
X-Band Simplex
•
X-Band Full Duplex
•
X-Band Simplex
8M083X25 R14
APX Series P25 Interface
Reference
Fig. 1 & 3
Fig. 2 & 4
Fig. 5 & 7
Fig. 6 & 8
Fig. 1 & 3
Fig. 2 & 4
Fig. 1 & 3
Fig. 2 & 4
Fig. 1 & 3
Fig. 2 & 4
Fig. 5 & 7
Fig. 6 & 8
Fig. 1 & 3
Fig. 2 & 4
Fig. 5 & 7
Fig. 6 & 8
Fig. 1 & 3
Fig. 2 & 4
Fig. 5 & 7
Fig. 6 & 8
Fig. 1 & 3
Fig. 2 & 4
Fig. 1 & 3
Fig. 2 & 4
Fig. 1 & 3
Fig. 2 & 4
