Ref PN
#
1a 7W083X05-01
1b 1W083B09-01
2 Control Head cable provided by Motorola
3 7W083X06-01
4 7W083X17-01
5 7W900X94-02
6 7W083X09-01
7 7W083X16-01
8 1W083A01-01

Table 8 Summary of DVRS Control and RF Cables

January 2019
DVRS Installation & Programming Guide – PART I
Length Order Code
3ft DDN9028
3ft DDN9029
2.5ft DDN9031
3ft DDN9034
3ft DDN2719A
1ft DDN9032
3ft DDN9033
18ft DDN9030
APX Series P25 Interface
Notes
DVR to MSU Control Cable
Custom lengths available – up to 25ft.
Replaces 1a if a Motorola Siren is to be interfaced
to the MSU.
Auxiliary Cable.
MSU to In-Band Filtering RF Cable
APX8500 to Notch filter RF Cable
RF switch option cable
DVR to In-Band Filtering RF Cable
DVR Power cable
