Introduction

The P25 Digital Vehicular Repeater (DVR) is designed to be seamlessly interfaced to:
•
Remote Mount APX Series Mobile Radios with or without a control head (O2, O3,
O5, O7 or O9)
Mobile Radio Model
APX2500
APX4500
APX6500
APX7500
APX8500
NOTE:
Mobile Radio must be configured as Remote Mount in order to be compatible with the
DVRS.
IMPORTANT!
This manual described the DVR models that are interfaced to the APX Series Mobile
Radios via P25 Interface. The MSU configured for DVRS operation can support up
to two Control Heads.
The P25 DVRS allows Portable Subscriber Units (PSU) to be used in areas where only
Mobile Subscriber Unit (MSU) coverage is available and portable radio coverage is either
intermittent or completely absent. Installed in the trunk of a car, fire truck, armored vehicle,
ambulance, the P25 DVRS extends radio communications to the PSU users who are
outside of the vehicle, inside a nearby building or in any marginal portable radio coverage
areas. The DVRS extends voice (analog or digital, clear or encrypted) communications
and supports key Trunking system features. The DVRS can be configured to provide
various advanced options to the users.
January 2019
DVRS Installation & Programming Guide – PART I
Firmware Requirements
R19.00.00 or later
R19.00.00 or later
R19.00.00 or later
R19.00.00 or later
R19.00.00 or later
8M083X25 R14
APX Series P25 Interface
Notes
Requires option GA00631
Requires option GA00631
Requires option GA00631
Requires option GA00631
Requires option GA00631
