Appendix 1 – DVR Specifications
General Specifications
Dimensions: Height / Width / Depth
Weight (DVR Only, without filtering)
Channel Spacing
Number of Channels
DC Current Drain
Standby/Receive
Operating Temperature
Protection Against Liquids
Antenna Impedance
External Connectors
Computer Interface
Equipment Type Acceptance
Transmitter Specification
Frequency Band [MHz]
Power Output @ Antenna Port
Max Spurious Output
Frequency Stability
FM Hum and Noise
Receiver Specification
Frequency Band [MHz]
Receiver Sensitivity
Frequency Stability
Selectivity 12.5 / 25 kHz
Deviation
FM Hum and Noise 12.5 / 25 kHz
Audio Output (Repeater Detect
January 2019
DVRS Installation & Programming Guide – PART II
185mm (7.28") / 186mm (7.32") / 315mm (12.41")
10.3kg (22.7lb)
12.5 or 25 kHz programmable
Up to 192
CTCSS/DCS Programmable per Channel
Power Supply 13.8V DC +/- 20%
RPTR Off 0.01 A Max
0.8 A Max
Transmit 4.5 A Max
-30ºC to +60ºC
IP54
50 Ohms
Duty Cycle Continuous
Antenna Mini UHF
USB
FCC LO6-DVRSVHF
ISED
2098B-DVRSVHF
136-174
10W (programmable per channel from 1W to
CCT Option
12.5 / 25 kHz
Audio Response
Audio Distortion
136-174
Intermodulation
12.5 / 25 kHz
600 mV RMS nominal, flat response
Audio)
Audio Response
Audio Distortion
VHF UHF
LO6-DVRSUHF
2098B-DVRSUHF
VHF UHF
380-430
450-470
470-512
10W)
15 sec to 15 min or Disabled
-20dBm
+/- 1.5ppm
37 dB / 43 dB
+1, -3 dB of 6 dB / octave pre-emphasis
characteristic over 300 Hz – 3 kHz
<2%
VHF UHF
380-430
450-470
470-512
-115 dBm
+/- 1.5ppm
60 dB / 75 dB
70 dB
+/-2.5 kHz / +/-5 kHz
37 dB / 43 dB
+1, -3 dB of 6 dB / octave de-emphasis
characteristic over 300 Hz – 3 kHz
<2%
8M083X25 R14
APX Series P25 Interface
700 800
LO6-DVRS700 LO6-DVRS800
2098B-DVRS700 2098B-DVRS800
700 800
764-776 851-870
700 800
794-806 806-825
