Table 13 Avra Functionality - Futurecom P25 Installation & Programming Manual

•
Activation / Deactivation: The DVRS activates when the VIP input is asserted
and deactivates when the VIP input is de-asserted.
•
Activation Only: The DVRS activates when the VIP input is asserted and does
NOT deactivate when the VIP input is de-asserted.
•
Toggle: The state of the DVR is toggled every time the VIP Input is asserted. No
action is taken when the VIP Input is de-asserted. This setting is intended to be
used when a car door switch is used as the AVRA trigger (opening the door
activates the DVR but closing it does not deactivate it).
The following table provides summary of the AVRA functionality as a function of the DVR
programming:
AVRA Configuration
Activation / Deactivation
Activation / Deactivation
Activation / Deactivation
Activation / Deactivation
Activation / Deactivation
Activation / Deactivation
Activation Only
Activation Only
Activation Only
Activation Only
Activation Only
Activation Only
Toggle
Toggle
Toggle
Toggle
Toggle

Table 13 AVRA Functionality

January 2019
DVRS Installation & Programming Guide – PART II
System Mode VIP Input
Allowed
True Asserted
False Asserted
True Asserted
False Asserted
True Asserted
True/False De-
asserted
True Asserted
False Asserted
True Asserted
False Asserted
True Asserted
True/False De-
asserted
True Asserted 1
False Asserted 1
True/False Asserted 2
True Asserted 2
True/False De-
asserted
