Analog Setup

Field Name
System Mode Enable /
Tones – Trailing
Disable Check
box.
System Mode Enable /
Tones – Lead
Disable Check
box.
Local Mode Enable /
Tones – Trailing
Disable Check
box.
Local Mode Enable /
Tones – Lead
Disable Check
box.
Portable Trunk Enable /
Simulated Disable Check
Access box.
Busy Lockout Enable /
MBX2 Disable Check
Compatibility box.
Busy Lockout 0 - 127
ID
0 – 180
Busy Lockout
Master Bit Clr minutes
Time
DTMF Remote Up to 5 digits.
Control Code
January 2019
DVRS Installation & Programming Guide – PART II
Range
Enables or Disables the Trailing Tones
sent by the DVR to the Local PSUs to
indicate state of the transmission.
The tones are sent at the end of LPSU
transmission.
Enables or Disables the Lead Go Ahead
Tones sent by the DVR to the Local
PSUs to indicate successful /
unsuccessful system channel access.
The tones are sent at the beginning of
LPSU transmission. The LPSU user
needs to do 'double PTT' in order to be
able to hear the Lead tones.
Enables or Disables the Trailing Tones
sent by the DVR to the Local PSUs to
indicate successful / unsuccessful DVR
transmission. The tones are sent at the
end of LPSU transmission.
Enables or Disables the Lead Go Ahead
Tones sent by the DVR to the Local
PSUs to indicate successful /
unsuccessful DVR transmission. The
tones are sent at the beginning of LPSU
transmission. The LPSU user needs to
do 'double PTT' in order to be able to
hear the Lead tones.
Enabled only when the PSU user is
expected to do 'Double PTT' and
Leading Tones are enabled.
When Enabled, the DVR changes its
voting algorithm, so it is compatible with
Mobexcom II VRs.
If MBX Compatibility is Enabled, each
DVR/VR needs to be programmed with a
different ID. Larger fleets may have
duplicate IDs programmed, preferably in
different operation areas.
If enabled (set to >0), the last DVR that
was voted a Primary will have a priority
in the next voting for the duration of the
timer. The timer is reset every time a
DVR is voted a Primary.
Upon receiving a matching DTMF
sequence from a PSU, the DVR switches
from OFF or Local to System Mode. The
DVR and PSU must be programmed with
the same DTMF sequence.
Description
8M083X25 R14
APX Series P25 Interface
Notes
Affects Analog DVR
Mode when used with
Trunked MSU mode
only. The tones are
heard by all LPSU users
that are on the selected
DVR channel since they
are sent over the air (not
generated in the LPSU).
Affects Analog DVR
Mode when used with
Trunked MSU mode
only. The tones are
heard by all LPSU users
that are on the selected
DVR channel since they
are sent over the air (not
generated in the LPSU).
The tones are heard by
all LPSU users that are
on the selected DVR
channel since they are
sent over the air (not
generated in the LPSU).
Affects Analog DVR
Mode when used with
Trunked MSU mode
only. The tones are
heard by all LPSU users
that are on the selected
DVR channel since they
are sent over the air (not
generated in the LPSU).
Default setting is 0 i.e.
Disabled and all DVRS
units have the same
chance of becoming a
Primary during every
voting. Applicable only
when MBX2 compatibility
is enabled.
The PSU must be
programmed with * as
the last DTMF sign, for
example 1234*.
