Specifications; Clearances, Dimensions, And Weights; Clearances - Danfoss VLT DriveMotor FCP 106 Design Manual

Specifications

6 Specifications

6.1 Clearances, Dimensions, and Weights

6.1.1 Clearances

To ensure sufficient airflow for the drive, observe the minimum clearances listed in Table 6.1.
When airflow is obstructed close to the drive, ensure adequate inlet of cool air and exhaust of hot air from the unit.
Enclosure
Enclosure Protection rating
size
MH1
IP66/Type 4X
MH2
IP66/Type 4X
MH3
IP66/Type 4X
Table 6.1 Minimum Clearance for Cooling
1) Power ratings relate to normal overload (NO), see chapter 6.2 Electrical Data.
2) The stated IP and Type rating only apply when the VLT
plate. Ensure that the gasket between the adapter plate and the motor has a protection rating corresponding to the required rating for the
combined motor and drive. As standalone drive, the protection rating is IP00 and Open type.
Enclosure size Maximum depth of hole into adapter plate (A)
[mm (in)]
MH1
MH2
MH3
Table 6.2 Details for Motor Adapter Plate Screws
1 2
1 Adapter plate
2 Screw
A Maximum depth of hole into adapter plate
B Maximum height of screw above adapter plate
Illustration 6.1 Screws to Fasten Motor Adapter Plate
MG03M302
Design Guide
Power 1)
[kW (hp)]
3x380–480 V
0.55–1.5 (0.75–2.0)
2)
2.2–4.0 (3.0–5.0)
2)
5.5–7.5 (7.5–10)
2)
®
DriveMotor FCP 106 is mounted on a wall mounting plate or a motor with the adapter
3 (0.12)
4 (0.16)
3.5 (0.14)
