5 Type Code and Selection Guide

5.1 Drive Configurator

Configure a drive according to the application requirements, using the order number system.
Order drive motors as standard or with internal options by using a type code string, for example:
FCP106N4K0T4C66H1FSXXA00
Refer to chapter 5.2 Type Code String for a detailed specification of each character in the string. Ordering numbers for drive
motor standard variants are available in chapter 5.3 Ordering Numbers.
To configure the correct drive for an application, and generate the type code string, use the internet-based Drive Config-
urator. The Drive Configurator automatically generates an 8-digit sales number to be delivered to the local sales office.
Furthermore, it can produce a project list with several products and send it to a Danfoss sales representative.
To access the Drive Configurator, go to: www.danfoss.com, and search for drive configurator.

5.2 Type Code String

Example of Drive Configurator interface set-up: The numbers shown in the boxes refer to the letter/figure number of the
type code string. Read from left to right.
Name Position
Product group 1–3
Series 4–6
Load profile, drive 7
Power size 8–10
Mains voltage 11–12
Enclosure 13–15
RFI filter 16–17
Fan option 18
Special version 19–21
Options 22–24
Table 5.1 Type Code Specification
1 2
F C
Illustration 5.1 Type Code String Example
MG03M302
Design Guide
Selection options
FCP
106
N: Normal overload
H: High overload
0.55–7.5 kW (K55–7K5)
T4: 380–480 V AC
C66: IP66/UL TYPE 4X
H1: RFI filter Class C1
F: With fan
SXX: Latest release - standard software
®
AX0: VLT Memory Module MCM 101
®
AO0: VLT Memory Module MCM 101, VLT
3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
P 1 0 6 T 4
Danfoss A/S © 12/2018 All rights reserved.
®
PROFIBUS DP MCA 101
P 6 6 H 1 F S X X A 0
