Specifications

6.3 Mains Supply

Mains supply (L1, L2, L3)
Supply voltage
Mains voltage low/mains dropout:
•
During low mains voltage or a mains dropout, the drive continues until the DC-link voltage drops below the minimum
stop level. This level typically corresponds to 15% below the lowest rated supply voltage of the drive. Power-up and full
torque cannot be expected at mains voltage lower than 10% below the lowest rated supply voltage of the drive.
Supply frequency
Maximum imbalance temporary between mains phases
True power factor (λ)
Displacement power factor (COSφ)
Switching on the input supply L1, L2, L3 (power-ups)
Environment according to EN 60664-1 and IEC 61800-5-1
The unit is suitable for use on a circuit capable of delivering not more than:
•
100000 RMS symmetrical Amperes, 480 V maximum, with fuses used as branch circuit protection.
•
See Table 6.7 and Table 6.8 when using circuit breakers as branch circuit protection.

6.4 Protection and Features

Protection and features
•
Electronic motor thermal protection against overload.
•
Temperature monitoring of the heat sink ensures that the drive trips when the temperature reaches 90 °C (194 °F)
±5 °C (41 °F). An overload temperature cannot be reset until the temperature of the heat sink is below 70 °C
(158 °F) ±5 °C (41 °F). However, these temperatures may vary for different power sizes, enclosures, and so on. The
drive autoderating function ensures that the heat sink temperature does not reach 90 °C (194 °F).
•
The drive motor terminals U, V, and W are protected against ground faults at power-up and start of the motor.
•
When a motor phase is missing, the drive trips and issues an alarm.
•
When a mains phase is missing, the drive trips or issues a warning (depending on the load).
•
Monitoring of the DC-link voltage ensures that the drive trips when the DC-link voltage is too low or too high.
•
All control terminals and relay terminals 01–03/04–06 comply with PELV (protective extra low voltage). However,
this compliance does not apply to grounded delta leg above 300 V.

6.5 Ambient Conditions

Environment
Enclosure protection rating
Enclosure protection rating FCP 106 between lid and heat sink
Enclosure protection rating FCP 106 between heat sink and adapter plate
FCP 106 wall mounting kit
Stationary vibration IEC61800-5-1 Ed.2
Non-stationary vibration (IEC 60721-3-3 Class 3M6)
Relative humidity (IEC 60721-3-3; Class 3K4 (non-condensing))
Aggressive environment (IEC 60721-3-3)
Test method according to IEC 60068-2-43
Ambient temperature
Minimum ambient temperature during full-scale operation
Minimum ambient temperature at reduced performance
Maximum ambient temperature at reduced performance
Temperature during storage
MG03M302
Design Guide
Danfoss A/S © 12/2018 All rights reserved.
380–480 V ±10%
3.0% of rated supply voltage
≥0.9 nominal at rated load
Near unity (>0.98)
Maximum 2 times/min.
Overvoltage category III/pollution degree 2
IP66/Type 4X
5–95% during operation
40 °C (104 °F) (24-hour average)
50 °C (122 °F)
-25 to +65 °C (-13 to +149 °F)
50/60 Hz
6 6
1)
IP66/Type 4X
IP66/Type 4X
IP66
Cl. 5.2.6.4
25.0 g
Class 3C3
H2S (10 days)
-10 °C (14 °F)
-20 °C (-4 °F)
