Dimensions; Weight - Danfoss VLT DriveMotor FCP 106 Design Manual

Specifications

6.1.2 Dimensions

6 6
Illustration 6.2 FCP 106 Dimensions
Enclosure
type
MH1
MH2
MH3
Table 6.3 Dimensions
1) Power ratings relate to normal overload (NO), see chapter 6.2 Electrical Data.

6.1.3 Weight

To calculate the total weight of the unit, add the weight of the combined drive and adapter plate, see Table 6.4.
Enclosure
size
MH1
MH2
MH3
Table 6.4 Weight of FCP 106
50
X
Length
1)
Power
[mm (in)]
[kW (hp)]
3x380–480 V A
0.55–1.5 (0.75–2.0) 231.4 (9.1) 130 (5.1) 162.1 (6.4) 106.8 (4.2)
2.2–4.0 (3.0–5.0) 276.8 (10.9) 166 (6.5) 187.1 (7.4) 113.2 (4.5)
5.5–7.5 (7.5–10) 321.7 (12.7) 211 (8.3) 221.1 (8.7) 123.4 (4.9)
Weight
FCP 106 Motor adapter Combined FCP 106
[kg (lb)] plate [kg (lb)] and motor adapter
plate [kg (lb)]
3.9 (8.6) 0.7 (1.5)
5.8 (12.8) 1.12 (2.5)
8.1 (17.9) 1.48 (3.3)
Danfoss A/S © 12/2018 All rights reserved.
®
VLT DriveMotor FCP 106
Y
Width
[mm (in)]
Normal lid
a B C
4.6 (10.1)
6.92 (15.3)
9.58 (21.2)
Height Cable gland
[mm (in)] diameter
High lid for
®
VLT PROFIBUS DP
MCA 101
option
C X
121.4 (4.8) M20
127.8 (5.0) M20
138.1 (5.4) M20
Mounting
hole
Y Z
M20 M6
M20 M6
M25 M6
MG03M302
